32 QUALITY REMANUFACTURED P RODUCTS FROM BENDIX COMMERCIAL VEHICLE SYSTEMS LLC

COMPRESSORS

HK1300

Midland Compressor Cylinder Head Repair Kit

This kit services Midland Compressors: All EL1300 and EL1600 Series Com-

pressors

Includes

Item No. Description Qty. Part No.

A Unloader Kit 1 UK1300

1 Cylinder Head Gasket 1 —

2 Discharge Port Gasket 1 —

3 Governor Gasket 1 —

4 Inlet Port Gasket 1 —

5 Exhaust Valve Springs 2 —

6 Exhaust Valve Seat 2 —

7 Copper Washer 4 —

8 Inlet Valve Seat 2 —

9 Exhaust Valve Plate 2 —

10 Inlet Valve Spring 2 —

11 Inlet Valve Cage 2 —

12 Inlet Valve Plate 2 —

AR3559511

Cummins Compressor Minor Cylinder Head Repair Kit

This kit services Cummins Compressors: 3018543X

Includes

Item No. Description Qty. Part No.

A Unloader Kit 1 UK8543

1 Head Block Gasket 1 —

2 Head Cover Gasket 1 —

3 Air Inlet Gasket 1 —

AR3559510

Cummins Compressor Major Cylinder Head Repair Kit (Early Style)

This kit services Cummins Compressors: 3018543X

Includes

Item No. Description Qty. Part No.

D Unloader Kit 1 —

B Mounting Gasket Kit 1 AR3559511

1 Unloader Valve Body 1 —

2 Unloader Cap 1 —

3 Exhaust Seat 1 —

4 Intake Valve Seat 1 —

REPAIR & GASKET KITS

AR3559509

Cummins Compressor Major Cylinder Head Repair Kit (Late Style)

This kit services Cummins Compressors: 3018543X

Includes

Item No. Description Qty. Part No.

A Unloader Kit 1 UK8543

B Mounting Gasket Kit 1 AR3559511

1 Unloader Valve Body 1 —

2 Unloader Cap 1 —

3 Exhaust Seat 1 —

4 Intake Valve Seat 1 —
