4. 



Figure 26. Cap Screw Removal

Figure 25. Retaining Ring and Washer Removal

5. 



6.





Figure 27. Anchor Pin Removal

Figure 28. Shoe Removal

Shoe Removal

ES-165-7H Severe Duty Brake

WARNING:





See General Information / Lining Material Warning

1.Removal

Disassembly - Drum Removal.

2.

3. 



Removal / Disassembly

Remove

Retaining

Rings and

Was

hers

Cut Lock Wire

and Remove

Cap Screws

Drive Out

Anchor Pin

Rotate Upper

Shoe Around

Cam End

Disengage Shoe

End From Cam . . .

Then Unhook

Return Spring

and Remove Shoe
