ECU Part Number Label

The external part number label is located above the control

port of the module. If this label is not readable for any

reason, the Bendix part number is etched into the module

casting above the control port (See Figure 1). A Bendix

manufacturing date code is to the right of the part number

inscription.

There is an additional label under one of the covers that

showsapin-outdiagramforthe18-pinmainconnector.

FIGURE 36 ‑ LABEL INFORMATION

Software Revision Level

ThenumberoftheinitialsoftwareloadedontheECUis

also indicated. The current software revision number can

be read using a diagnostic tool.

Document Revision Level

Please visit Bendix.com to ensure you have the latest

version of this document.

Date of Manufacture Code

Bendix Part Number

YYWWDAAAAYYWWD

AXXX

Knorr-Bremse 00 A

K004243

XXXXXXXX

Final 8 Digits

Show Initial

Software

Loaded
