• Pigtail Wiring Harness: A power pigtail harness is

required,variationsthatincludeauxiliarysub-harnesses

are available, as needed. See Figure 6.

• Lift Axle Sensing: Ifatrailerisequippedwithaliftaxle,

thenliftaxlesensingmustbeused,unlesscongured

for automatic lift axle control (see below). A pressure

threshold switch must be installed in the lift bag for the

liftaxleandconnectedtotheECU.TheECUcanthen

monitor the position of the lift axle and will compensate

correctly for the load transfer to the other axle(s) when

the lift axle is raised.

• Lift Axle Control: The Bendix

TABS‑6

™

Adv can be

conguredtoautomaticallyraise(andlower)liftaxle(s)

whenapre-conguredloadissensed.

• Load Sensor: Ifatrailerisequippedwithanexternal

electrical spring deection sensor, See Figure 3, a

linkage is attached to an axle (but must not be installed

onaliftaxle)—within5(ve)inchesofthecenterof

the axle — connects to a load sensor attached to the

chassis of the vehicle. The output from the sensor is

an electrical signal that is proportional to the spring

deection.Theconnection totheElectronicControl

Unit(ECU)isviaanauxiliarysub-harness(partofthe

power harness). See Figure 6.

FIGURE 6 ‑ EXAMPLES OF PIGTAIL WIRE HARNESSES

To ECU

To WS-24

™

Wheel

Speed Sensor

Wheel Speed Sensor

Extension Harness

Pigtail Harness

6-pin Auxiliary

(Optional)

18-Pin ECU Connector

4-Pin SAE J1939 CAN

(Optional)

4-Pin SAE J1939 CAN

(Optional)

4-Pin SAE J1939 CAN

5-Pin Power and

Indicator

Lamp (POWER/WL)

5-Pin Power and

Indicator

Lamp (POWER/WL)

5-Pin Power and

Indicator

Lamp (POWER/WL)
